Visualizing data, by Cleveland
Monday June 29, 2026
"We cannot learn efficiently about nature by routinely taking the rich information in data and reducing it to a single number." (page 85)
I have developed some gripes with Cleveland's 1993 book, but there's a lot to like too. I feel like some of this school of data visualization techniques has been lost.
One thing he does throughout is try to catch errors in other people's work. It's fairly engaging, but he does sometimes come off as a bit of a scold.
What should a data/visualization book do? It feels like there's too much to cover, in some ways. Cleveland is opinionated and bites off a specific chunk.
The visualization of statistical data has always existed in one form or another in science and technology. For example, diagrams are the first methods presented in R. A. Fisher's Statistical Methods for Research Workers, the 1925 book that brought statistics to many in the scientific and technical community. (page 2)
So that's Cleveland. And here's what Fisher said:
The preliminary examination of most data is facilitated by the use of diagrams. Diagrams prove nothing, but bring outstanding features readily to the eye ; they are therefore no substitute for such critical tests as may be applied to the data, but are valuable in suggesting such tests, and in explaining the conclusions founded upon them. (page 25, Statistical Method For Research Workers)
Fisher and Cleveland are quite far apart here! I could imagine Cleveland saying "hypothesis tests prove nothing if they are unsupported by diagrams." And for some tests at least, for example tests of distribution ("is this data normal?") Cleveland seems to promote visualization-only.
The histogram is a widely used graphical method that is at least a century old. But maturity and ubiquity do not guarantee the efficacy of a tool. The histogram is a poor method for comparing groups of univariate measurements. ... The venerable histogram, an old favorite, but a weak competitor, will not be encountered again. (page 8)
I used part of this fun quote in my first presentation on pavement plots.
Cleveland differentiates between data with multiple quantitative variables (bivariate, trivariate, hypervariate) and data with a single quantitative variable and multiple categorical variables ("multiway"). He uses his "multiway dot plot" for that case.
Cleveland doesn't mention, as far as I recall, the all-categorical case. I think that case is the focus of Geometric Data Analysis (Le Roux and Rouanet) which I meant to understand. Something about PCA on cross-tabs, I think, which would put it in the family of converting categorical to quantitative. That family also includes, much more popularly these days, embeddings.
The general case is a bunch of categorical and quantitative variables. What to do?
Cleveland puts "f-value" ("fraction" of the data) on the x axis (page 16 and throughout) and I think this is not a good choice, usually... I did it that way in a plot a while back and people pointed out it's not the typical way to do a CDF. (Also "f-value" just isn't a great term, I think.)
Cleveland cites (page 21) Wilk and Gnanadesikan as originators of the q-q plot, which might even be right, but I don't see an open access copy of the paper to check in more depth. Bell Labs loves to cite Bell Labs.
Oh right: and a Tukey mean-difference plot is a sort of transform on a q-q plot. (pages 22-23) Hardly ever see these... Cleveland uses it to argue for an additive shift structure between two groups of singer heights. Cleveland also often calls it an "m-d" plot and makes you remember what that means.
Thought: is it always good to de-mean quant vars in regression so that the intercept is more interpretable? (otherwise what, average value for zero-height people? etc.)
On page 24 Cleveland does "Pairwise Q-Q Plots" which we might also call a q-q matrix, analogously to a scatterplot matrix... I wondered about simplifying it to compare each group to the overall distribution, but at that point I'd probably just do pavement plots anyway.
On qq plots... Drawing a line connecting the first and third quartiles? That's always seemed a little weird to me. Why that?
Cleveland introduces (page 40) "residual-fit spread plots" ("r-f spread plots") which are sort of a visual way of getting at the R2 idea of "variance explained." But it doesn't show the spread of the original data itself, so you could imagine some strange situations, possibly.
One thought is that often this is all done in a transformed domain, which can obscure how successful the model really is in the untransformed domain...
In section 2.6, Cleveland introduces random dot stereograms. It's a data example (for log transforms) but I think later he wants to suggest we might use them as data visualizations in 3D. (They don't work for me at all and have not caught on.)
There's a discussion of kurtosis around page 70. The terminology drives me nuts a little bit. Leptokurtosis has lepto meaning "thin," but these are the fat-tailed ones. Then platykurtosis is from platy meaning "broad," but these feel like narrower distributions if we consider the whole shape. The tail behavior is what drives the measure, but the names focus on the middle part of the distribution, maybe? Just seems a little confusing. (Never mind other ways kurtosis can be misleading.)
Cleveland mentions how in 1969 Edwark Fowlkes was making systems supporting direct manipulation of visualized data (removing outliers, etc.) - these kinds of things are still not commonly supported in most visualization systems.
(Also, in trying to look up Fowlkes' work, I came across a neat history of data visualization!)
The fusion-time experimenters based their conclusions on rote data analysis: probabilistic inference unguided by the insight that visualization brings. They put their data into an hypothesis test, reducing the information in the 78 measurements to one numerical value, the significance level of the test. The level was not small enough, so they concluded that the experiment did not support the hypothesis that prior information reduces fusion time. Without a full visualization, they did not discover taking logs, the additive shift, and the near normality of the distributions. Such rote analysis guarantees frequent failure. We cannot learn efficiently about nature by routinely taking the rich information in data and reducing it to a single number. Information will be lost. By contrast, visualization retains the information in the data. (page 85)
Cleveland is sometimes concerned, not quite with general heteroskedasticity, but with monotone spread. On page 50 he introduces the "spread-location plot" ("s-l plot") which has fitted value on the x axis and square root absolute residual on the y axis.
The square root transformation is used because absolute residuals are almost always severely skewed toward large values, and the square root often removes the asymmetry. (page 51)
I'm not so sure... Kind of a lot of choices baked into this one, and you lose the ability to see patterns in over vs. under-predicting (because of taking absolute value).
A ratio, which has a numerator and denominator, is a strong candidate for a log transform. When the numerator is bigger, the ratio can go from 1 all the way to infinity, but when the numerator is bigger, the ratio is squeezed into the interval 0 to 1. The logarithm symmetrizes the scale of measurement; when the numerator is bigger, the log ratio is positive, and when the denominator is bigger, the log ratio is negative. The symmetry often produces simpler structure. (page 110)
Sort of assuming numerator and denominator are both positive measurements, but yeah, this makes sense.
Thought: You could do a q-q plot as a slope graph instead of a scatterplot, and this might even be better for showing which parts of the distributions are relatively squished or spread out. It would be like having parallel pavement plots with corresponding quantiles connected by lines.
Cleveland really likes loess, including seasonal loess (page 170). I'm not as much of a fan, but Hadley seems to have been on the loess train, so maybe I'm wrong?
I'm reminded that I don't really know a good way to evaluate how likely a dataset is to have come from a particular distribution... I mean I know there's Kolmogorov-Smirnov, but I don't know the details and I don't know a general approach... Surely we can just get, given a distribution, log-likelihood of all the data or something?
Probabilistic inference was carried out using a standard t-interval method that is based on an assumption that the deviations of the response from the line are a homogeneous random sample from a normal population distribution.
...
The rote data analysis of the experimenters has produced nonsense. The visualizations earlier in the chapter showed that a line does not fit the data. That ends matters right there. The standard t-interval method is not valid. The sampling variability that it prescribes for the estimate is not the actual variability.
...
The visualizations of the chapter also showed that a quadratic polynomial fits CP ratio without lack of fit, but there is monotone spread. So even with the right function, the t-interval method is inapplicable because the residuals are not homogeneous. (page 177)
Coplots (as on page 189) are pretty neat... Trying to "hold constant" one variable by looking at scatterplot of two others in small multiples binned over the control variable in narrow-ish bins.
This kind of thing is hard enough that it just isn't done usually, I think... Or it's done with a partial regression controlling things out, maybe. (I wonder how these might compare...)
Just as an interesting terminology thing, Cleveland uses "lack of fit" and "surplus of fit," which I think correspond to what we usually call "underfit" and "overfit."
The mistreatment of these data by the experimenter and others who analyzed them will be taken up at the end of this chapter. (page 217)
There are pretty many of these punchy quotes...
For this scientific application, the nonlinear surface is not worth the cost. (page 226)
Cleveland throws in a few judgement calls like this. His reasoning is explained, but they're still judgement calls, I think.
Data analysis is difficult. Serendipity should be exploited. (page 232)
How things get measured is a fascinating topic. And a critical one, of course. In many domains of science, brilliance and great ingenuity abound in measurement techniques. This intellectual effort is crucial because measurement is the foundation of scientific enquiry. (page 257)
Visual linking is the reason, despite the redundancy, for including both the upper and lower triangles in the scatterplot matrix; the upper left triangle has all pairs of scatterplots, and so does the lower right triangle. (page 275)
Fisher was a brilliant scientist who also was a pioneer of mathematical genetics. (page 328)
Cleveland is a little uncomfortably uncritical of Fisher's work.
Cleveland closes his book arguing that the Morris portion of the barley dataset has the years backward. Maybe so. At least one person has argued that it isn't backward.
